UTC-S0862A
8-inch industrial Panel PC, die-cast aluminum housing, fanless, 0~50°C temperature range (extended option), IP65 front panel, 12V DC input (optional 9-36V DC). Intel Celeron J1900 CPU, 4-8GB DDR3L RAM, full-size mSATA SSD + 2.5-inch SATA SSD storage.
- One-piece die-cast aluminum housing, fanless design
- 0~50°C temperature range, optional extended range
- IP65-rated front panel
- 12V DC input (3-pin aviation connector), optional 9-36V DC
Contact us for a quote. We don’t have enough basis to publish a reference range for this model — we quote precisely once we know the configuration you need.
Industrial factors
| Mounting | VESA Mount |
|---|---|
| Dimensions (mm) | 219.2x177.2x64.8 |
| Weight (kg) | 2.3 |
| Certifications | CE, RoHS |
Computing
| CPU | Intel Celeron J1900 (Bay Trail-D) |
|---|---|
| RAM | DDR3L · 1 slots · up to 8GB |
| Storage | mSATA SSD (full size) · SATA 2.5" SSD |
| GPU | Intel HD Graphics |
| PCI/PCIe expansion slots | 0 |
Connectivity & I/O
| COM | 3× RS232 (DB9), optional 2xRS485 or 2xRS422 |
|---|---|
| LAN | 2× Gigabit Intel I211 |
| USB | 5× USB USB 2.0 Type-A · 1× USB USB 3.0 Type-A |
| Display outputs | 1× HDMI · 1× VGA |
Display
| Screen size | 8" |
|---|---|
| Resolution | 1024x768 |
| Brightness (nit) | 300 |
| Touch | Projected Capacitive Touch |
| Front IP rating | IP65 |
