UNO-2484G-6531BE
Máy tính công nghiệp mô-đun không quạt chuẩn IP40, dải nhiệt -20 đến 60°C, nguồn DC 10-36 VDC, hỗ trợ Win 7/10/Linux, tích hợp chip Intel Core i5 thế hệ 6 (dành cho khu vực Mỹ).
- Chịu được nhiệt độ -20 đến 60°C, chống sốc 50G và chống rung 3 Grms
- Thiết kế không quạt, chuẩn bảo vệ IP40 bằng vỏ hợp kim nhôm
- Đa dạng tùy chọn hệ điều hành bao gồm Windows 7, Windows 10 và Linux
- Nguồn điện công nghiệp 10 - 36 VDC
This is a reference range for the barebone unit, excluding RAM and storage. IPC247 engineers advise on a full configuration for your use case.
Industrial factors
| Operating temperature range | -20 ~ 60 °C (với luồng khí 0.7 m/s, 5 ~ 85% RH) |
|---|---|
| Power input | 10 - 36 VDC |
| Power connector | 1 x 2 Pins Terminal Block |
| Mounting | Stand, Wall, VESA, DIN-rail |
| Dimensions (mm) | 200 x 140 x 40 |
| Weight (kg) | 1.4 |
| Vibration resistance | 3 Grms, ngẫu nhiên, 5 ~ 500 Hz, 1 giờ/trục — IEC 60068-2-64 |
| IP protection rating | IP40 |
| Certifications | CE, FCC, UL, CCC, BSMI |
Computing
| CPU | Intel Core i5-6300U |
|---|---|
| RAM | DDR4 · up to 16GB |
| Storage | 1× mSATA · 2× SATA 2.5" SSD/HDD |
| GPU | Intel HD Graphics 520 |
| PCI/PCIe expansion slots | 0 |
Connectivity & I/O
| COM | 4× RS-232/422/485 |
|---|---|
| LAN | 4× 10/100/1000 Mbps |
| USB | 4× USB USB 3.0 |
| Display outputs | 1× HDMI 1.4 · 1× DP 1.2 |
| Expansion | 1× mPCIe |
Need a complete-set price with RAM, storage and mounting accessories for this model? Leave your number — an engineer will reply within 4 working hours.
We only use this number to answer your request.
Optional accessories & modules (20 items)
| PCM-24S2WF-CE | 802.11 a/b/g/n 2T2R w/ Bluetooth4.0, Half-size mPCIe, 2-port SMA |
|---|---|
| PCM-24R2GL-AE | 2-Port Gigabit Ethernet, mPCIe, RJ45 |
| PCM-24D2R2-BE | 2-Port Isolated RS-232 mPCIe, DB9 |
| PCM-24D4R4-BE | 4-Port Non-Isolated RS-422/485 mPCIe, DB37 |
| PCM-24R1TP-BE | 1-Port Gigabit Ethernet, mPCIe, RJ45 |
| PCM-27D24DI-AE | 24-Channel Isolated Digital I/O w/ counter mPCIe, DB37 |
| 96PSA-A150W24T2-4 | Power Adapter 150W |
| 96PSA-A120W24T2-4 | Power Adapter 120W |
| 1702002600 | Power Cable US Plug 1.8 M (Industrial Grade) |
| UNO-REPWR-AE | Remote power & reset kit |
| 1702002605 | Power Cable EU Plug 1.8 M (Industrial Grade) |
| 1702031801-11 | Power Cable UK Plug 1.8 M (Industrial Grade) |
| 1700000596-11 | Power Cable China/Australia Plug 1.8 M (Industrial Grade) |
| UNO-2000G-VMKAE | UNO-2000 VESA Mount Kit |
| UNO-2000G-DMKAE | UNO-2484G DIN RAIL Kit |
| UNO-2000-LKAE | Cable lockable kit 10 units/per pack |
| UNO-2484G-VEGA330 | UNO-2484G 1st stack bottom plate for VEGA-330 |
| UNO-2484G-EKBE | UNO-2484G 2nd stack expansion module for 4 iDoor |
| UNO-2484G-S2AE | UNO-2484G external swappable HDD extension kit |
| UNO-2484G-PCIEAE | UNO-2484G second stack PCIex4 expansion module |
