UTC-S1262A
12-inch industrial Panel PC, one-piece die-cast aluminum housing, fanless design, supports both AT & ATX power modes, IP65-rated front panel. 12V DC power, optional wide 9-36V DC range for industrial control cabinets. Equipped with Intel Celeron J1900 processor, 4-8GB DDR3L RAM, 12-inch capacitive touchscreen (optional 1000 nits brightness), plus 3 COM ports and 6 USB ports for field device integration.
- One-piece die-cast aluminum housing, fanless design
- Supports both AT & ATX power modes
- 12V DC power, optional wide 9-36V DC range
- IP65-rated front panel, dust and splash resistant
Contact us for a quote. We don’t have enough basis to publish a reference range for this model — we quote precisely once we know the configuration you need.
Industrial factors
| Certifications | CE, RoHS |
|---|
Computing
| CPU | Intel Celeron J1900 |
|---|---|
| PCI/PCIe expansion slots | 0 |
Connectivity & I/O
| COM | 3× RS232, DB9 · 2× RS485/RS422 (optional) |
|---|---|
| LAN | 2× 10/100/1000Mbps |
| USB | 5× USB USB2.0 · 1× USB USB3.0 |
| Display outputs | 1× HDMI · 1× VGA |
| Expansion | 1× Mini-PCIe |
Need a complete-set price with RAM, storage and mounting accessories for this model? Leave your number — an engineer will reply within 4 working hours.
We only use this number to answer your request.
Optional accessories & modules (2 items)
| VESA Bracket | |
| Power Cable 3-pin 200cm |
