Panel PC Advantech TPC-300

TPC-315-R853B

Máy tính bảng điều khiển công nghiệp 15 inch thiết kế không quạt, vỏ nhôm đúc đạt chuẩn bảo vệ IP66 mặt trước, hoạt động ở dải nhiệt -10~55°C, nguồn 24 VDC ±20%. Tích hợp vi xử lý Intel Core i5-8365UE, sẵn 8GB DDR4 RAM và hỗ trợ khe mở rộng iDoor linh hoạt.

Thiết kế công nghiệp không quạt, vỏ nhôm đúc bảo vệ nối đất và mặt trước đạt chuẩn IP66 chống bụi/nước
Dải nhiệt độ hoạt động rộng từ -10 đến 55°C, nguồn cấp 24 VDC ± 20%
Màn hình cảm ứng điện trở 5 dây mặt phẳng hoàn toàn (True-flat)
Hỗ trợ mở rộng iDoor cho giao thức fieldbus, I/O cách ly, truyền thông Wi-Fi/4G/5G/GPS

giá tham khảo · updated 2026-08-09

54.600.000đ – 89.200.000đ

This is a reference range for the barebone unit, excluding RAM and storage. IPC247 engineers advise on a full configuration for your use case.

Get configuration advice Compare this machine Find equivalent products

Or leave your phone number — an engineer will quote model TPC-315-R853B within 4 working hours.

Industrial factors

Operating temperature range	-10 ~ 55 °C (w/o air flow)
Power input	24 VDC ± 20%
Power connector	3-pin Plug-In Block
Mounting	VESA Mount, Desktop, Wall Mount, Panel Mount
Dimensions (mm)	383.2 x 307.3 x 66.5
Weight (kg)	5.8
Vibration resistance	1 Grms (5 ~ 500 Hz)
IP protection rating	IP66 (front panel)
Certifications	BSMI, CCC, CE, FCC Class A, CB, UL

Computing

CPU	Intel Core i5-8365UE
RAM	DDR4 SO-DIMM · 2 slots · up to 64GB
Storage	1× M.2 2280 M Key (SATA / NVMe PCIe x4) · 1× M.2 2242/3042/3052 B Key (SATA / PCIe / USB3.0) · 1× 2.5" SATA SSD/HDD (Max. 7mm)
PCI/PCIe expansion slots	0

Connectivity & I/O

COM	2× RS-232/422/485
LAN	2× 1 GbE / 2.5 GbE
USB	1× USB USB 2.0 · 4× USB USB 3.2 Gen 2
Display outputs	1× DisplayPort
Expansion	1× Full-size Mini PCIe · 1× iDoor slot · 1× SIM Slot

Display

Screen size	15"
Resolution	1024 x 768
Brightness (nit)	300
Touch	5-wire resistive
Frame type	Die cast aluminum alloy
Front IP rating	IP66

Need a complete-set price with RAM, storage and mounting accessories for this model? Leave your number — an engineer will reply within 4 working hours.

We only use this number to answer your request.

Optional accessories & modules (21 items)

96PSA-A120W24T2-4	120W 24VDC power supply
1702002600	Power cable (US) 1.8 M
1702002605	Power cable (EU) 1.8 M
1702031801	Power cable (UK) 1.8 M
1700000596-11	Power cable (China/Australia) 1.8 M
PPC-STAND-A1E	Stand For HMI Series
PPC-ARM-A03	ARM VESA Standard (A-CLEVER)
PPC-174T-WL-MTE	Wall mount kit A800B for HMI
PCM-24D2R2-BE	Isolated RS-232, DB9 x 2, (USB type)
PCM-24D2R4-BE	Isolated RS-422/485, DB9 x 2, (USB type)
PCM-24D4R2-BE	Non-Isolated RS-232, DB37 x 1 (USB Type)
PCM-24D4R4-BE	Non-Isolated RS-422/485, DB37 x 1 (USB Type)
PCM-27D24DI-AE	Digital I/O, 16 DI / 8 DO, Isolation, DB37 x 1
PCM-24R2GL-AE	2 Port Giga LAN Intel i350 PCIe mini card
PCM-24R2PE-AE	Intel i350, GbE, PoE IEEE 802.3af, PD, RJ45 x 2
PCM-24U2U3-BE	PCM-24U2U3, 2-Port USB 3.0, mPCIe
PCM-24S2WF-CE	802.11 a/b/g/n/ac 2T2R w/BT4.1, Intel AC9260
PCM-23C1CF-CE	1 slot Cfast iDoor for CFast with PWR cable
PCM-23U1DG-CE	Internal locked USB Slot for USB Dongle, mPCIe
PCM-26D2CA-BE	SJA1000 CANBus, Lattice, CANOpen, DB9 x 2
PCM-26D2CA-CE	USB CANBus, CANOpen, DB9 x 2

Other configurations in the TPC-300 series

Same chassis, same mounting — they differ in screen size and CPU. If the model above isn’t quite right, switching to one of these is usually enough.

TPC-307W-PE20A 7″ · Atom X6211E TPC-307W-PE20AU 7″ · Atom X6211E TPC-310W-PE20A 10.1″ · Atom x6425E TPC-310W-PE20AU 10.1″ · Atom x6425E TPC-310W-PJ20A 10.1″ · Celeron J6412 TPC-312-R833B 12.1″ · Core i3-8145UE TPC-312-R853B 12.1″ · Core i5-8365UE TPC-312-R873B 12.1″ · Core i7-8665UE

See the whole TPC-300 series and compare configurations →

Equivalent products from other series

Different series — some even a different brand — but the same machine type with closely matching key specs. We cross-check compatibility against the manufacturer’s documentation before quoting.

CV-W115FHR-R10/P2302E-R10 Cincoze CV-100/P2302

15.6″ · Core Ultra 7 / 5 / 3 (Meteor Lake-PS) · 4× COM · 2× LAN · -40 ~ 65 °C
