PBQ-900L
Qseven carrier board in EPIC form factor, withstands a wide operating temperature range of -40~85°C and up to 95% non-condensing humidity, suited for mounting inside industrial control cabinets. Accepts a wide DC input of 10~30V, paired with an Arbor Qseven CPU module (e.g. EmQ-i2200) to form a complete system.
- Qseven® R2.0 carrier board in EPIC form factor
- 2x Gigabit Ethernet ports
- 2-channel 24-bit LVDS
- Wide operating temperature range: -40 ~ 85°C
Contact us for a quote. We don’t have enough basis to publish a reference range for this model — we quote precisely once we know the configuration you need.
Or leave your phone number — an engineer will quote model PBQ-900L within 4 working hours.
Industrial factors
| Operating temperature range | -40 ~ 85 °C |
|---|
Computing
| Storage | SATA connector · NGFF (M.2) socket Skt1-M cho SSD SATA |
|---|---|
| PCI/PCIe expansion slots | 0 |
Connectivity & I/O
| COM | 3× RS-232 · 1× RS-232/422/485 selectable · 1× UART |
|---|---|
| LAN | 1× Gigabit Ethernet Intel i210IT PCIe GbE controller · 1× Gigabit Ethernet (qua Qseven CPU Module) |
| USB | 1× USB USB 2.0 · 2× USB USB 3.0 Super Speed (depending on CPU module) |
| Display outputs | 1× DVI · 1× LVDS 24-bit Dual Channel |
| Expansion | 1× SMBus port · 1× I2C port · 1× NGFF (M.2) socket Skt1-E · 1× SD card socket · MXM socket |
Need a complete-set price with RAM, storage and mounting accessories for this model? Leave your number — an engineer will reply within 4 working hours.
We only use this number to answer your request.
Optional accessories & modules (1 items)
| CBK-06-900L-00 | Cable Kit: 1x USB cable, 2x COM cables, 1x SATA cable, 1x SATA power cable, 1x AUDIO cable |
|---|
