MaytinhcongnghiepP2302 · compute module
One series, 2 configurations.
Compute module only, mounted onto the back of a matching display frame.
- -40~65°COperating temp
- FanlessCooling
- 9–48 VDCPower input
- up to 4COM ports
- up to 2LAN ports
- up to 1PCIe slots
True for every configuration in the series
The items below stay the same whichever configuration you pick — no need to re-check after choosing.
- Operating temperature range
- -40 ~ 65 °C
- DC power input
- 9–48 VDC
- COM ports
- 4 ports
- LAN ports
- 2 ports
- Power over Ethernet
- No PoE
- Digital I/O (DIO)
- Yes
- Cooling
- Fanless (passive)
Choose a configuration
Filter quickly, then click a model number for the full specs. Not sure which one, send us your installation conditions and our engineers will pick for you.
| Select for comparison | Model number | CPU | Environment | Ports · I/O | Reference price |
|---|---|---|---|---|---|
| P2302-R10 | Meteor Lake-PS Core Ultra 7/5/3 Processor | -40~65°C Fanless · 9–48 VDC | 4 COM · 2 LAN DIO | ||
| P2302E-R10 | Meteor Lake-PS Core Ultra 7/5/3 Processor | -40~65°C Fanless · 9–48 VDC | 4 COM · 2 LAN · 1 PCIe DIO |
No configuration matches these filters. Remove a condition, or ask an engineer — the version you need may be orderable even if it is not on the site.
Tick 2–3 configurations in the first column to put them side by side — the comparison page highlights exactly the cells that differ, so you don’t have to scan every row.
Not sure which configuration fits?
Describe the installation site — temperature, vibration, power supply, devices to connect — and IPC247 engineers will build a complete configuration for those conditions.
