MaytinhcongnghiepUTC-W10
One series, 7 configurations. The configurations differ in 7 CPU options — everything else is identical.
Display and computer in one unit, mounted straight onto the cabinet face.
- 0~50°COperating temp
- IP65Ingress rating
- FanlessCooling
- up to 5COM ports
- up to 2LAN ports
True for every configuration in the series
The items below stay the same whichever configuration you pick — no need to re-check after choosing.
- Operating temperature range
- 0 ~ 50 °C
- Resolution
- 1280x800 (1920x1200 optional)
- Display brightness
- 300 nit
- LAN ports
- 2 ports
- Power over Ethernet
- No PoE
- Digital I/O (DIO)
- No
- Cooling
- Fanless (passive)
- Touch screen
- Capacitive
Choose a configuration
Filter quickly, then click a model number for the full specs. Not sure which one, send us your installation conditions and our engineers will pick for you.
Showing 7 / 7 configurations
| Select for comparison | Model number | Display | CPU | Environment | Ports · I/O | Reference price |
|---|---|---|---|---|---|---|
| UTC-W1062A | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Celeron J1900 (Bay Trail-D) | 0~50°C · IP65 (FRONT PANEL) Fanless · 12–9 VDC | 3 COM · 2 LAN — | ||
| UTC-W1062A-1 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Baytrail-D Celeron J1900 | 0~50°C · IP65 (FRONT PANEL) Fanless · — | 5 COM · 2 LAN — | ||
| UTC-W1082A-1 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Core i3-7100U | 0~50°C · IP65 FRONT PANEL Fanless · — | 5 COM · 2 LAN — | ||
| UTC-W1082A-2 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Core i5-7200U | 0~50°C · IP65 FRONT PANEL Fanless · — | 5 COM · 2 LAN — | ||
| UTC-W1092B-1 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Core i3-10110U | 0~50°C · IP65 FRONT PANEL Fanless · 9–36 VDC | 2 LAN — | ||
| UTC-W1092B-2 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Core i5-10210U | 0~50°C · IP65 FRONT PANEL Fanless · 9–36 VDC | 2 LAN — | ||
| UTC-W1092B-3 | 10.1″ · 1280x800 (1920x1200 optional) 300 nit · Capacitive | Core i7-10510U | 0~50°C · IP65 FRONT PANEL Fanless · 9–36 VDC | 2 LAN — |
No configuration matches these filters. Remove a condition, or ask an engineer — the version you need may be orderable even if it is not on the site.
Tick 2–3 configurations in the first column to put them side by side — the comparison page highlights exactly the cells that differ, so you don’t have to scan every row.
Not sure which configuration fits?
Describe the installation site — temperature, vibration, power supply, devices to connect — and IPC247 engineers will build a complete configuration for those conditions.
