C8.02.01.010
CESIPC UPC-108H fanless industrial computer, customizable LEGO MODE modular design, integrated 4000mAh backup battery protecting against sudden power loss, wide 9-36V DC power input, 0~50°C operating range (optional extended -40~70°C), 10-90% non-condensing humidity, MTBF 60,000 hours, aluminum body with Bracket/VESA mount. Optional Intel Core i3-7100U / i5-7200U / i7-7500U (7th Gen) CPU, DDR4 RAM up to 16GB, mSATA SSD storage.
- Integrated 4000mAh backup battery protects data and the system against sudden power loss.
- Fanless design, extruded 6063 aluminum body combined with metal panels, 1.95kg weight, Bracket Mount or VESA Mount installation.
- Wide 9-36V DC power input via a 2-pin pluggable terminal block, with an AT/ATX mode switch and optional ATX On/Off power button.
- Standard operating range 0~50°C (optional extended -40~70°C), storage -10~60°C, 10-90% non-condensing humidity, MTBF 60,000 hours.
Contact us for a quote. We don’t have enough basis to publish a reference range for this model — we quote precisely once we know the configuration you need.
Industrial factors
| Operating temperature range | 0 ~ 50 °C (standard; extended range -40~70°C optional) |
|---|---|
| Mounting | Bracket Mount, VESA Mount |
| Dimensions (mm) | 195 x 160 x 65.3 (W x D x H); cutout 229 x 160 x 68.5 |
| Weight (kg) | 1.95 |
| Certifications | CE, FCC, EN 55032, EN 55035, EN IEC 61000-3-2, ISO9001:2015 |
Computing
| PCI/PCIe expansion slots | 0 |
|---|
Connectivity & I/O
| COM | 2× RS232 |
|---|---|
| LAN | 2× Intel I210 |
| USB | 2× USB 2.0 · 4× USB 3.0 |
| Display outputs | 1× VGA · 1× HDMI |
