AEC-8000
High-performance box-type embedded AI computer, operating temperature -25°C~50°C with airflow, DC 9~36V input with selectable AT/ATX mode plus ACC/IGN control, cooled by SOM fan + 2 chassis fans — NVIDIA Jetson Thor T5000 128GB platform, performance up to 2070 TFLOPS, base configuration without additional PoE/GMSL/USB expansion.
- Operating temperature range -25°C ~ 50°C (TDP 77W fan mode, with 0.63 m/s airflow)
- Wide-range DC input 9~36V, selectable AT/ATX mode, with ACC IN/IGN control (ACC optional)
- NVIDIA Jetson Thor T5000 128GB LPDDR5X platform, Blackwell GPU with 2,650 cores, performance up to 2070 TFLOPS
- 2 x GbE + 1 x QSFP 4x25GbE, up to 8 x USB 3.2 (depending on BTO configuration), 2 x M.2 M-key for SSD, 4G/5G and Wi-Fi 6E slot
Contact us for a quote. We don’t have enough basis to publish a reference range for this model — we quote precisely once we know the configuration you need.
Or leave your phone number — an engineer will quote model AEC-8000 within 4 working hours.
Industrial factors
| Operating temperature range | -25 ~ 50 °C (77W TDP Fan mode, 0.63 m/s air flow) |
|---|---|
| Power input | 9~36V |
| Power connector | 3-pin terminal block |
| Mounting | Wallmount |
| Dimensions (mm) | 211 x 194 x 111 |
| Weight (kg) | 4 |
| Vibration resistance | Category 4 — MIL-STD-810G Method 514.6 Procedure I (TBA) |
| Certifications | CE, FCC, EN50155 (TBA), EN50121-3-2 (TBA) |
Computing
| CPU | 14-core Arm® Neoverse™ V3AE 64-bit CPU |
|---|---|
| RAM | LPDDR5X · up to 128GB |
| Storage | M.2 Key M (2280) NVMe, PCIe Gen5 x2 (shared with 8xPoE/8xUSB board) · M.2 Key M (2280) NVMe, PCIe Gen5 x4 |
| GPU | 2,650-core NVIDIA Blackwell™ GPU with 5th GEN 96 Tensor Cores |
| CUDA cores | 2650 |
| PCI/PCIe expansion slots | 0 |
Connectivity & I/O
| COM | 2× RS-232/422/485 |
|---|---|
| LAN | 2× GbE (1 port supports optional NCSI/OOB) · 1× QSFP 4x25GbE |
| USB | 4× USB USB 3.2 Type-A · 1× USB USB 3.2 Type-C · 1× USB USB 3.2 Type-C (OTG, requires BSP installation) |
| DIO | 8 in / 8 out |
| Display outputs | 1× USB Type-C DP Alt mode · 2× HDMI |
| Expansion | 1× 2x10-pin Euro Terminal Block · 1× M.2 B-key · 1× M.2 E-key · 2× M.2 M-key · 2× SIM |
